Phased Array I

Phased Array I Course

Register by calling 617-378-2067
Course Number: 102-PA40-WK1
Title: Phased Array I - Week 1 of 2
Duration: 5 day course, 40 hours total
Dates: On demand - Contact us to schedule
Cost: $1,500

Prerequisites: UT Level II
Format: Classroom PP with live Phased Array technology demonstrations
Class Size: 4 to 8 students per class
Audience: UT Shear Wave Technicians

Week 1 for UT Shear Wave Technicians

This course covers advanced ultrasonic concepts that are outlined in ASNT CP105, which are critical for understanding and performing code compliant Phased Array inspections.

Learn how to:

- Generate and Receive ultrasonic waves in “phased” groups

- Create a Single Group for Manual inspection and Multiple Groups for Automated inspection

- Focus Beams for optimal calibration and resolution using appropriate Focal Laws

Students who complete the course will benefit by having an understanding of the theory, concepts, and capabilities of phased array technology. This formal course is the first step toward receiving ASNT certification using the UT Phased Array technique.

Course Outline

Day 1
Terminology, History, Responsibility Levels of Certification
Theory of Wave Generation, Phased Array Concepts

Day 2
PA Probes, PA Wedges, and Scanners
Portable and PC based Phased Array Systems

Day 3
PA Test Techniques, Linear imaging, Sectorial imaging
PA Calibrations, Sensitivity, Wedge delay, Time Corrected Gain

Day 4
Probe Exit Point Verification, Beam Steering, Acquisition Gates
Scan Plans, Data Collection, Single Probe, Multiple Probes, Encoded data

Day 5
Data Evaluation, Flaw Characterization, and Flaw Sizing
Reporting
